This file is the ETA-K3 datasheet, which introduces the features and characteristics of ETA-K3, including rated current, pin spacing, installation method, etc.
The EZC43DREH is a high‑density board‑to‑board connector offered by Sullins. It supports a 3 A current rating and a maximum contact resistance of 10 mΩ at rated current. The connector can be built with PBT or PPS insulators and offers molded‑in key options for secure contact retention.
A variety of mounting styles are provided, including side mounting, threaded inserts, floating bobbin, and versions with no mounting ears. Termination types cover right‑angle, eyelet (standard or overall plated), and dip‑solder options. Detailed dimensions, contact finishes (gold, tin, nickel with specified thicknesses), and part‑number coding are included to aid selection and assembly.
| Current rating | 3 A |
|---|---|
| Maximum contact resistance | 10 mΩ |
| Insulator material options | PBT or PPS |
| Supported PCB thicknesses | 0.062" and 0.008" (others on request) |
| Contact finish thicknesses | Gold .000010", Tin .000100", Nickel .000050" |
| Number of contact positions | 05 through 60 |
It is rated for 3 A of current.
The maximum contact resistance is 10 mΩ.
The connector can be built with either PBT or PPS insulators.
It accommodates .062" and .008" thick PCBs, with other thicknesses available on request.
