TMS320R2811 and TMS320R2812 Digital Signal Processors are new products in the sampling or preproduction phase of development. Characteristic data and other specifications are subject to change without notice.
The manual presents detailed information on the TMS320R2811 and TMS320R2812 digital signal processors, including hardware features, pin assignments for various packages, and functional block diagrams. It also covers memory maps, peripheral modules, and timing specifications.
Additional sections provide electrical specifications such as absolute maximum ratings, recommended operating conditions, and current consumption, as well as mechanical data for BGA, LQFP, and PBK packages, including thermal resistance and reflow temperature limits.
