The ultrasonic vibration micro nozzle consists of a piezoelectric ceramic and a metal foil, which atomizes water or liquids through thousands of micro holes. The product features fine and consistent misted particle size, adjustable misted particle size, no loaded liquids required, high atomizing efficiency, less power consumption, high stability, and durability. It is suitable for humidification in refrigerated food displays and storage, living environments, and air conditioning plants, inhalation and disinfecting equipment, humidification in industrial process control, and liquids dispensing systems.
The ultrasonic vibration micro nozzle uses a piezoelectric ceramic and metal foil to atomize water or liquids through a matrix of 7‑10 µm micro holes, similar to an ink‑jet printer. It can draw small liquid amounts via siphon, offering higher atomizing efficiency than conventional ultrasonic atomizers that require a full liquid tank.
Features include fine and consistent mist particle size, adjustable mist size, no need for loaded liquids, high atomizing efficiency, low power consumption, and high stability. It is suited for humidification in refrigerated food displays, living environments, air‑conditioning plants, inhalation and disinfecting equipment, industrial process control, and liquids dispensing systems.
| Model Number | M2313500 |
|---|---|
| Resonant Frequency | 135 kHz ±5 kHz |
| Impedance | 10 Ω typ. |
| Capacitance | 2450 pF ±20 % |
| Dimensions | L 29.20 mm × W 17.35 mm × T 1.0 mm |
| Nozzle Size | 7‑10 µm |
| Metal Material | Ni‑Co Alloy |
| Frequency Adjustment Range | 130 kHz – 140 kHz |
It provides a fine and consistent misted particle size with the ability to adjust the mist size.
The resonant frequency is approximately 135 kHz, with a tolerance of ±5 kHz.
