The document provides information about the features and characteristics of Visualux Ltd products, including CCFL Inverters, Cold Cathode Fluorescent Lamps, and LED lighting panels.
The Visualux Designers Guide provides an overview of the company’s backlight product lines, including S‑Series, E‑Series, SA‑Series and PCB‑mounted modules. It describes the three main LCD display types—reflective, transflective and transmissive—and explains how the backlights are suited to each.
Technical data sheets for the backlights are included, covering mechanical properties, thermal and electrical characteristics, as well as a detailed list of CCFL inverter part numbers and dimensions.
| Tensile Strength | 65‑68 N/mm² |
|---|---|
| Dielectric Strength | 40 kV/mm |
| Light Transmission | 92 % |
| Thermal Conductivity | 0.19 W/m°C |
| Coefficient of Linear Thermal Expansion | 0.08 mm/m°C |
A Visualux backlight can last up to 100,000 hours, comparable to the life of a typical LCD.
The dielectric constant is 3.4 at 10 Hz.
