SyncMaster P2370HD P2570HD P2770HD LCD TV Monitor User Manual, this user manual mainly introduces the product's safety usage precautions, installation methods, usage methods and other contents, please read carefully.
This manual provides safety precautions, installation steps, and usage instructions for the Samsung SyncMaster P2370HD, P2570HD, and P2770HD LCD monitors. It includes guidance on mounting, connecting cables, adjusting the on‑screen display, and using optional features such as power‑saving mode.
Technical specifications, power‑saving details, and contact information for Samsung worldwide are also included, helping users set up the monitor correctly and maintain it safely.
| Screen Size | 23" (P2370HD), 24.6" (P2570HD), 27" (P2770HD) |
|---|---|
| Resolution (Optimal) | 1920 × 1080 @ 60 Hz |
| Maximum Pixel Clock | 162.000 MHz |
| Input Signal | RGB analog, DVI compatible digital RGB |
| Power Voltage | AC 100‑240 V, 50/60 Hz |
| Dimensions (Without Stand) | 571 × 364.6 × 65.5 mm (P2370HD) |
| VESA Mounting Interface | 75 mm × 75 mm (P2370HD), 100 mm × 100 mm (P2570HD/P2770HD) |
| Operating Temperature | 50 °F ~ 104 °F (10 °C ~ 40 °C) |
| Power Consumption (Power‑Saving Mode) | P2370HD <2 W, P2570HD <1 W, P2770HD <1 W |
The P2370HD complies with a 75 mm × 75 mm VESA mounting interface.
Maintain a viewing distance of about 45 ~ 50 cm (15 ~ 19 inches) from the screen.
