This document introduces the Miniature Sensor Series from Banner Engineering International, including VS1 Micro Focused Self-contained Sensor, VS2 Micro Self-contained Sensor, VS3 Micro Self-contained Sensor, VS4 Micro Self-contained Sensor, T8 Mini Self-contained Sensor, Q10 Mini Self-contained Photoelectric Sensor, Q14 Mini Self-contained DC Sensor, MINI-BEAM®2 Mini Photoelectric Sensor, and Q23 & QH23 Mini DC Photoelectric Sensor. These sensors are characterized by high quality and low cost, and can be used in various applications.
This manual covers the VS1 series sensors from Banner Engineering, detailing their electrical ratings, mechanical dimensions, and mounting options. It includes wiring diagrams, output type information, and environmental specifications.
Key sections include product specifications, installation procedures, wiring and connection guidelines, and troubleshooting tips to help users set up and maintain the sensors correctly.
| Operating voltage | 10 ~ 30 V DC |
|---|---|
| Operating temperature range | -20°C ~ +55°C |
The VS1 sensor operates from 10 to 30 volts DC.
It can be used in temperatures from –20 °C to +55 °C.
