The TT... series temperature transmitters are used to convert temperature signals into standard DC signals of 0V~10V or 4mA~20mA. The temperature sensitive elements used are platinum resistance Pt100, Pt1000, and NTC thermistor. The features of the transmitters include high reliability, low drift, compact size, and standard rail mounting. The current output transmitters comply with EMC standards.
The TT series temperature transmitter converts temperature signals to standard 0‑10 V or 4‑20 mA outputs. It supports Pt1100, Pt1000 and NTC sensing elements and complies with EMC standards.
The device is powered by 15 V or 24 V supplies, can be mounted according to DIN 43800 EN 50022‑35 standards, and features an ABS enclosure with IP30 protection. Installation and wiring details are provided for various sensor types and output ranges. This manual is written in Chinese.
| Output signal | 0‑10 V or 4‑20 mA |
|---|---|
| Power supply | 15 V, 24 V |
| Accuracy | +0.59 % to +1.09 % |
| Pressure range | 86 kPa – 108 kPa |
| Temperature range | 0 °C – 50 °C |
| Relative humidity range | 10 % – 90 % RH |
| Enclosure material | ABS |
| Protection rating | IP30 |
| Installation standard | DIN 43800 EN 50022‑35 x 7.5 |
The transmitter can output either a 0‑10 V voltage signal or a 4‑20 mA current signal.
It can be powered from 15 V or 24 V sources.
The device measures temperatures from 0 °C to 50 °C.
The enclosure is made of ABS plastic and has an IP30 protection rating.
