TD-6110… series electronic temperature sensors and transmitters are used to measure air, water and oil medium temperature. Widely used in HVAC, heating, cooling and other temperature automatic control system. The product features: can flexibly choose various types of temperature sensors; the temperature transmitter with built-in temperature sensor, can output DC0V ~ 10V or 4mA ~ 20mA standard signal, temperature range can be selected; the pipe material is copper or stainless steel, and the length can be provided according to the need; wind pipe or water pipe temperature measurement, to choose different installation accessories, easy to install on site and maintenance afterwards; the shell is made of fire-proof materials; the cable locking mouth, tight seal; can transmit signals over long distances.
The TD-6110 series includes temperature sensors and transmitters designed for indoor, water, oil and other medium temperature measurements. They support Pt100, Pt1000, and NTC (K2, K10) sensing elements and provide either voltage (0‑10 V) or current (4‑20 mA) standardized signals.
Installation guidelines cover proper mounting locations, avoidance of direct sunlight or heat sources, and selection of appropriate pipe‑diameter accessories. The manual also lists environmental limits, IEC/EN compliance, and accessory part numbers for various pipe sizes. This manual is written in Chinese.
| Operating temperature range | -200 °C to 70 °C |
|---|---|
| Relative humidity range | 10%‑90% |
| Supported sensor elements | Pt100, Pt1000, NTC K2, NTC K10 |
The series supports Pt100, Pt1000, and NTC thermistors K2 and K10.
The devices operate from –200 °C up to 70 °C.
The allowed relative humidity is between 10% and 90%.
