The OP196/OP296/OP496 is a micropower, rail-to-rail input and output operational amplifier with low power consumption, single-supply operation, and high open-loop gain. It is suitable for applications such as battery monitoring, sensor conditioning, portable power supply control, and portable instrumentation.
The OP196, OP296 and OP496 operational amplifiers from Analog Devices provide micropower operation with rail‑to‑rail input and output. Their low offset voltage (as low as 300 pV) and low bias current make them suitable for battery monitoring, sensor conditioning, and portable instrumentation.
These devices operate from 3 V to 12 V, offer a gain‑bandwidth product of 350 kHz (450 kHz typical), a slew rate of 0.3 V/µs, and are available in 8‑lead SOIC, 8‑lead TSSOP, 8‑lead Plastic DIP, 14‑lead SOIC, and 14‑lead TSSOP packages.
| Gain Bandwidth Product | 350 kHz |
|---|---|
| Supply Voltage Range | 3 V to 12 V |
| Slew Rate | 0.3 V/µs |
| Available Packages | 8‑Lead SOIC, 8‑Lead TSSOP, 8‑Lead Plastic DIP, 14‑Lead SOIC, 14‑Lead TSSOP |
The devices operate from 3 V up to 12 V.
The typical gain‑bandwidth product is 350 kHz (450 kHz in some specifications).
The slew rate is 0.3 V/µs.
The OP196 is offered in 8‑lead SOIC, 8‑lead TSSOP, and 8‑lead Plastic DIP packages.
