LMV331 is a single channel comparator, LMV393 is a dual channel comparator, and LMV339 is a quad channel comparator. They are low voltage (2.7-5V) versions of LM393/339, which are specified at 5-30V. LMV331 offers space-saving SC70-5 and SOT23-5 packages. LMV393 is available in 8-pin SOIC and 8-pin MSOP packages. LMV339 is available in 14-pin SOIC and 14-pin TSSOP packages. LMV331/393/339 are the most cost-effective solution in circuit design for portable consumer products where space, low voltage, low power, and price are the primary specifications. They offer specifications that meet or exceed the familiar LM393/339, but with only a fraction of the supply current. The chips are built with National's advanced Submicron Silicon-Gate BiCMOS process. LMV331/393/339 have bipolar input and output stages for improved noise performance.
The LMV331 (single), LMV393 (dual) and LMV339 (quad) are low‑voltage (2.7‑5 V) versions of National Semiconductor's classic comparators, offered in space‑saving SC70‑5, SOT23‑5, SOIC, MSOP and TSSOP packages. They provide low supply current, wide input common‑mode range and open‑collector outputs suitable for portable consumer devices.
The document includes absolute maximum ratings, DC and AC electrical characteristics, typical performance curves, a simplified schematic, and example application circuits with hysteresis. Physical dimensions for each package and compliance notes are also provided.
| Supply Current (LMV331, 2.7 V) | 40‑100 µA max |
|---|---|
| Input Offset Voltage (LMV331, 5 V) | 1.7‑7 mV |
| Input Bias Current (LMV331) | 10 pA max |
| Output Saturation Voltage | 200 mV |
| Operating Temperature Range | -40 °C to +85 °C |
The LMV331 draws 40‑100 µA maximum supply current at a 2.7 V supply.
The input offset voltage is specified as 1.7‑7 mV.
It is rated for an industrial temperature range of –40 °C to +85 °C.
