The HIB-C15 series current sensor is a measuring module that converts the measured current into a proportional output current or voltage using the Hall closed-loop principle. The primary and secondary windings are highly isolated. It has the characteristics of high precision, high linearity, high integration, small structure, simple structure, long-term stable operation and adaptability to various working environments. It is widely used in the system control and testing of electrical equipment in the fields of power, petroleum, coal mine, chemical industry, railway, communication, and building automation.
The HIB-C15 series current sensor from Passion Technology measures AC, DC, and mixed currents up to 300 A rms. It offers high accuracy, compact size, and a magnetic‑balance principle for reliable operation in industrial applications such as power, oil, chemical, railway, and building automation.
The manual provides product introduction, detailed specifications, mechanical dimensions, electrical connection diagrams, output characteristics, and safety guidelines. It also lists recommended supply voltage, output current options, temperature limits, and installation instructions. This manual is written in Japanese.
| Output current (O9) | 50 mA |
|---|---|
| Output current (O10) | 100 mA |
| Output current (O12) | 150 mA |
| Bandwidth | DC‑100 kHz |
The sensor provides output currents of 50 mA (O9), 100 mA (O10), and 150 mA (O12).
