This document is a catalog of LEMO connectors, listing various LEMO connector models and their application scenarios.
This catalogue presents LEMO's extensive range of unipole and multipole connectors, covering series such as B, K, S, E, and many mixed‑type families. It includes details on housings, insulators, contact types (solder, crimp, print), keying systems, and available configurations from 2 A up to 150 A and high‑voltage options up to 50 kV.
Technical data such as IP68 watertight protection, current ratings for various conductor sizes, and wiring‑gauge tables are provided, along with information on accessories, tooling, panel cut‑outs, and patch panels for audio, video, and fiber‑optic applications.
| IP Rating | IP68 watertight |
|---|---|
| Maximum current (0.08 mm² conductor, Group 2) | 1.0 A |
| Maximum current (0.50 mm² conductor, Group 2) | 9.0 A |
LEMO connectors are rated IP68, offering watertight protection.
The connector is disengaged by pulling the outer release sleeve, which first releases the latches and then withdraws the plug.
A 0.34 mm² conductor can carry up to 6.0 A in Group 2.
