This document is an introduction to the production program and product characteristics of LEMO USA Inc. It includes information about different series and types of products, LEMO's push-pull self-latching connection system, single contact and multicontact connectors production program, IP68 watertight assembly selection, contact type selection, model description, etc.
This manual presents the complete description of LEMO single‑contact and multicontact connectors. It covers nearly 40 series divided into seven product families, each with detailed information on plug, receptacle, coupler and bridge plug models, contact configurations, and environmental ratings.
The document also includes selection guidelines for watertight and vacuum‑tight connectors, technical tables for wire gauges, and a full list of accessories and tooling required for assembly and testing.
| IP rating for watertight series | IP68 |
|---|---|
| Maximum number of contacts per multicontact connector | 106 |
| Maximum cable diameter | 30 mm |
| Current rating for single‑contact connectors | 2 – 150 A |
| Watertight protection code | IEC 60529/IP 68 |
LEMO watertight connectors are rated IP68.
A multicontact connector can accommodate up to 106 contacts.
The connectors support a maximum cable diameter of 30 mm.
Single‑contact connectors are rated for currents from 2 A up to 150 A.
