This document is an instruction manual for a camera, describing its features and how to use it.
This manual explains how to install the PSP‑450x camera on a PlayStation Portable (PSP) system, including inserting the camera into the USB connector and securing it with the mounting screw. It describes the macro mode selector, microphone usage, and lens specifications, and notes that the device requires PSP system software version 6.00 or later.
Safety and regulatory information are covered, with warnings about keeping the camera away from children, dust, liquids, and extreme temperatures. Warranty details (one‑year limited warranty) and FCC/ICES compliance statements are also included.
| Effective pixels | Approx. 0.3 megapixels |
|---|---|
| Lens | Wide‑angle F2.8, focal length 28 mm (35 mm equivalent) |
| Standard recording distance | 20 cm (≈7.9 in) |
| Macro recording distance | 6‑7 cm (≈2.4‑2.8 in) |
| Warranty period | 1 year from date of purchase |
| Required PSP software version | 6.00 or later |
| FCC classification | Class B digital device |
The camera is covered by a one‑year limited warranty from the date of purchase.
The PSP system software must be version 6.00 or later.
Place the subject about 6‑7 cm (2.4‑2.8 in) from the camera when using macro mode.
