CMDF2-4ADP is a temperature acquisition extension module developed by JTP Technology Co., Ltd. for PLC, DCS, PCS, computers and other control and data acquisition systems. It supports MODBUS RTU RS-485 communication and has line break alarm mode settings and digital/temperature data (output according to temperature value×10). The working voltage is DC 9～30V wide range power input, lightning protection and power reverse connection protection.
The CMD F2-4ADP is a temperature acquisition module designed for PLC, DCS, PCS and PC control systems. It provides four 3‑wire PT‑100 inputs with 12‑bit resolution and supports Modbus RTU communication over an isolated RS‑485 interface.
The manual covers hardware specifications, wiring diagrams, communication settings, parameter configuration through the JTconfig software, and troubleshooting tips. Power can be supplied from 9 V to 30 V DC, and the device operates at baud rates from 600 to 115200 bps. This manual is written in Chinese.
| Power supply | DC 9 V – 30 V |
|---|---|
| Baud rate | 600 bps – 115200 bps |
It can be powered from a DC source between 9 V and 30 V.
