D6DS is an industrial design star-delta start timer with 2 normally open contacts.
The Timers D6DS is an industrial timer featuring a star‑delta start‑up, two normally opened contacts, and a self‑extinguishing plastic housing with IP40 protection. It mounts on a DIN‑rail (TS‑35) and offers a wide supply voltage range (24 V DC, 24 V AC, 110‑240 V AC).\n\nThe device provides adjustable start‑up and transit times, high switching capacity, and robust mechanical and electrical life ratings. It operates within –25 °C to +55 °C ambient temperature and complies with IEC standards for accuracy and safety.
| Width | 22.5 mm |
|---|---|
| Number of contacts | 2 normally opened |
| Supply voltage options | 24 V DC, 24 V AC, 110‑240 V AC |
| IP rating | IP40 |
| Mounting | DIN‑Rail TS‑35 (EN 50022) |
| Initial torque | max 1 Nm |
| Mechanical life | 20 × 10⁸ operations |
| Electrical life | 2 × 10⁵ operations |
| Maximum load (250 V AC) | 1250 VA (5 A) |
| Maximum load (250 V AC) | 2000 VA (8 A) |
| Switching frequency (100 VA load) | max 60 /min |
| Ambient temperature range | -25 °C to +55 °C |
The D6DS can be powered from 24 V DC, 24 V AC, or a universal AC range of 110 V to 240 V.
The contacts are rated for 20 × 10⁸ operations.
The housing is made of self‑extinguishing plastic with an IP40 rating.
