This manual introduces safety, installation, dimensions, wiring, etc. of ACOPOS series products.
This manual describes the safety precautions required when handling ACOPOS servo drives, including protection against high‑voltage contact, low‑voltage isolation, and measures to prevent unintended motion. It also explains the meaning of status LEDs and the required grounding procedures.
The document then details the installation process, dimension drawings, wiring connections for power, DC bus, motor and brake resistors, as well as cable and connector pin‑assignments for various interfaces such as CAN, Ethernet Powerlink, EnDat, and rotary‑transformer modules. This manual is written in Chinese.
| Protective grounding (PE) required | Yes |
|---|---|
| Low‑voltage isolation threshold | 40 V |
| Current leakage limit | 3.5 mA |
| Maximum DC bus length | 3 m |
