3ND583 Low Noise Fractional Stepper Driver User Manual, introduces the product's features, characteristics, parameters, wiring, application scenarios and other information
This manual introduces the 3ND583 low‑noise, low‑heat stepper driver, its electrical, mechanical and environmental specifications, and typical application fields such as engraving machines, laser plotters and CNC equipment. Detailed sections cover driver interfaces, wiring, current and micro‑stepping settings, power‑supply selection, motor compatibility, typical wiring examples, protection functions and warranty terms.
The document also includes a comprehensive FAQ that addresses common setup problems, protection mechanisms and recommended power‑supply ranges, helping users install and maintain the driver safely and efficiently. This manual is written in Chinese.
| Maximum Output Current | 8.3 A (average 5.9 A) |
|---|---|
| Input Voltage Range | 18 V – 50 V DC |
| Step Pulse Frequency | up to 400 kHz |
| Operating Temperature Range | 0 °C to +50 °C |
| Insulation Resistance | 500 MΩ |
| Weight | ≈ 280 g |
The driver can deliver a peak output current of 8.3 A (average 5.9 A).
A DC supply of 24 V‑45 V is recommended, with a permissible range of 18 V‑50 V.
If the input voltage exceeds 51 V DC, the over‑voltage protection circuit activates and the power‑indicator turns red.
The driver supports step pulse frequencies up to 400 kHz.
