This document provides technical specifications and material characteristics for all categories of metallized fabric and foam products available from Laird Technologies. These products include UL94 V0 and HB flame retardant material, ideal for applications requiring low compression.
The Laird Metallized Conductive Products Handbook presents detailed technical data for a wide range of EMI shielding solutions, including fabric‑over‑foam gaskets, conductive foams, conductive fabrics, and conductive tapes. It is intended for design engineers who need material properties, dimensions, and part numbers to select the right shielding component.
Key sections include a part‑number cross‑reference, profile and I/O construction options, profile selection guides, I/O gasket selection, and ordering information. Performance benefits such as shielding effectiveness, low surface resistivity, flame‑retardant ratings, and temperature ranges are highlighted throughout the catalog.
| Shielding Effectiveness | >100 dB (MIL‑STD‑285 mod.) |
|---|---|
| Surface Resistivity | < 0.07 Ω/square |
| Service Temperature Range | -40 °F to 158 °F |
| Compression Force | 5‑10 lbs/ft |
They achieve shielding effectiveness greater than 100 dB according to MIL‑STD‑285 (mod.).
The fabrics have a low surface resistivity of less than 0.07 Ω per square.
They are rated for service temperatures from –40 °F to 158 °F.
