The C.A 1880 is an industrial thermal imaging camera that is rugged, compact, easy to use and water-proof. It can record 1,000 radiometric images, measure distances from 10 cm and automatically recognise hot and cold spots. The C.A 1880 is equipped with easy-to-use software that has many tools (cursors, profiles, zones, arrays, etc.) for effective analysis. The software also supports data export to Word reports.
The C.A 1880 (RayCAm) is an industrial thermal imaging camera designed for preventive maintenance, fault detection and temperature monitoring of equipment such as generators, motors and electrical connections. It features a rugged, compact design with a 2.5" colour LCD and up to 1,000 recordable thermograms.
The manual details detector technology, performance parameters, measurement functions, software reporting, power options and accessories. It also includes application notes for electrical, mechanical and thermal use cases, as well as lens specifications and ordering information.
| Detector type | UFPA Microbolometer / 8‑14 µm |
|---|---|
| Resolution | 160 × 120 pixels, 9 Hz |
| Temperature range | -20 °C to +250 °C |
| Accuracy | ±2 °C to ±2 % |
| Power source | 7.2 V Li‑ion battery, 8‑11 V DC |
| Battery autonomy | ≈ 2 hours |
| Operating temperature | -25 °C to +50 °C |
| Storage temperature | -40 °C to +70 °C |
| NETD (30 °C) | 0.12 °C |
| Field of view | 20° × 15°, IFOV 2.2 mrad |
| Weight | < 700 g |
| Video output | PAL / NTSC |
| Display | 2.5" colour LCD |
It can measure temperatures from –20 °C up to +250 °C.
The battery provides approximately 2 hours of operation.
It uses an UFPA microbolometer with an 8‑14 µm spectral band.
Up to 1,000 thermograms (stored in 250 files) can be recorded.
