JVL MAC50, MAC95, MAC140 Integrated Servo Motors Service Manual

This manual describes the technical details of the JVL Industri Elektronik A/S MAC50, 95 and 140 integrated servo motors.

JVL MAC50, MAC95, MAC140 Integrated Servo Motors Service Manual - cover page
Brand
JVL
Category
Servo motor
Document type
Service Manual
Language
English
Pages
88
File format
PDF
File size
329 KB
Published
09 April, 2012
Updated
30 September, 2023
MD5 checksum
B6F19F943F1F83A8BED1237D71BF54FF
PDF
JVL MAC50, MAC95, MAC140 Integrated Servo Motors Service Manual PDF

About this manual

This technical manual describes advanced use of the MAC series integrated servo motors. It covers the functions, data registers, and communication interfaces of the MAC50, MAC95, and MAC140 models.

The document also explains the sampled‑system operation, regulation loops, and programming functions, offering technicians the necessary details for maintenance, troubleshooting, and system integration.

What's inside

  • Introduction
  • Sampled Systems
  • MacReglO Software
  • Parameter and Data Description
  • Program/Function Description
  • Interface Description
  • Index

Specifications

Number of regulation loops3
Current‑loop sampling frequency7812 Hz
Velocity/position‑loop sampling frequency521 Hz

Frequently asked questions

How many regulation loops does the MAC motor have?

The MAC motor contains three regulation loops.

What is the sampling frequency for the current regulation loops?

The current regulation loops operate at a sampling frequency of 7 812 Hz.

What interfaces are provided by the MAC motor?

The MAC motor supports RS232 and RS422 communication interfaces.

Download PDF (329 KB)
