This manual describes how to use XXX device
This manual provides an overview of the mainboard features, including the VIA P4X333 Northbridge and VT8235/8233A Southbridge chipsets, AC'97 audio, USB ports, and ATX form factor. It also includes a checklist of package contents and safety precautions for installation.
The guide covers detailed installation steps, BIOS setup, and software utilities such as flash memory tools and driver installation procedures, helping users configure and maintain the system.
| Processor socket | Socket‑478 PGA |
|---|---|
| Supported CPUs | Intel Pentium 4 series |
| Front‑Side Bus speed | Up to 533 MHz |
| Chipset | VIA P4X333 Northbridge, VT8235/VT8233A Southbridge |
| Memory slots | 4 DIMM slots (2 DDR + 2 SDR), up to 1 GB |
| PCI slots | Four 32‑bit PCI slots |
| AGP slot | 4x AGP |
| USB ports | Six (two back‑panel, four via headers) |
| Audio | AC'97 2.1 compliant |
| Ethernet | 10BaseT/100BaseTX Fast Ethernet |
| Form factor | ATX 305 mm × 244 mm |
It uses a Socket‑478 PGA socket that supports Intel Pentium 4 processors.
The board supports front‑side bus speeds up to 533 MHz.
Six USB ports are available – two on the back panel and four via onboard headers.
The motherboard uses the VIA P4X333 Northbridge together with VT8235 or VT8233A Southbridge.
