This document is a traditional Chinese user manual, which introduces the specifications and features of a motherboard, including CPU support, AGP slots, PCI slots, etc.
This manual describes the Intel EP-3PTA motherboard based on the Intel 82815EP B stepping chipset. It lists the supported CPU socket, expansion slots, power connectors, and hardware monitoring features.
It also provides detailed jumper settings for CPU/DIMM frequency, CMOS clear, and keyboard power‑on, as well as instructions for installing memory modules and using the various onboard connectors. This manual is written in Japanese.
| CPU socket | Socket 370 |
|---|---|
| AGP slots | 4X |
| PCI slots (32‑bit) | 6 |
| DIMM slots (168‑pin) | 3 |
| Power connector | ATX |
| USB connector | USB |
| BIOS CPU Vcore adjustment | Supported |
Set jumper JP2 to the 2‑3 position to clear CMOS.
