935-X48T31-500G 05900824E System Board User's Manual
This manual covers safety precautions, handling instructions, and warranty information for the DFI X48‑T3RS system board. It explains how to protect the board from electrostatic discharge, outlines the package contents, and details the required components for a successful installation.
Technical sections describe the processor socket, supported CPUs, chipset, memory architecture, expansion slots, audio and LAN modules, as well as BIOS features and troubleshooting procedures. The document also includes a multilingual table of contents and references to additional resources on DFI’s website.
| CPU socket | LGA 775 |
|---|---|
| Supported CPUs | Intel® Core™? Quad and Intel® Core™2 Duo |
| Chipset | Intel® X48 Express |
| Memory slots | Four 240‑pin DDR3 DIMM sockets |
| Maximum memory | 8 GB |
| Expansion slots | 2 PCI Express Gen 2 x16 slots |
| LAN controller | Marvell 88E8052 / 88E8053 Gigabit LAN |
| Audio codec | Realtek ALC885 8‑channel HD Audio |
Use an antistatic wrist strap, work on a static‑free surface, keep the board in its anti‑static bag until ready, and handle it by the edges only.
The warranty is void if the product is misused, physically abused, improperly installed, modified, accidentally damaged, or repaired by an unauthorized party.
The package includes four Serial ATA data cables.
