I86PE-A4 is a mainboard of Kingston which has hardware, BIOS and software characteristics
This manual describes the I86PE-A4 motherboard features, supported CPUs, chipsets, memory configurations, and connector layouts. It includes detailed hardware installation instructions, jumper settings, and BIOS setup procedures.
The document also offers troubleshooting tips for power, keyboard, and boot issues, as well as guidance on resetting CMOS and updating firmware. This manual is written in Chinese.
| Supported CPU | Pentium 4, Celeron, Celeron D, Northwood, Prescott (not Willamette) |
|---|---|
| CPU Socket | Socket‑478 |
| Chipset | Northbridge Intel 865PE, Southbridge Intel ICH5 |
| Maximum Memory | 4 GB DDR (non‑registered, x8/x16) |
| Memory Slots | 1‑2 DDR channels, up to 2 DIMM per channel (64‑128‑256‑512‑1024 MB modules) |
| Audio Codec | ALC655, 6‑channel, supports S/PDIF I/O |
| USB Ports | 4 × USB 2.0 |
| SATA/IDE | 2 × SATA, 4 × IDE (PIO 0‑4, Ultra DMA 33/66/100) |
Check that the power cable is properly connected to the motherboard.
Set the JCMOS1 jumper to the ON position to clear the CMOS data.
The board supports up to 4 GB of DDR memory in one or two channels, using 64‑128‑256‑512‑1024 MB modules, only non‑registered DIMMs.
It supports Pentium 4, Celeron, Celeron D, Northwood and Prescott processors, but not Willamette.
