K8VGA-M is a motherboard that supports DDR2 SDRAM and integrated graphics
This manual covers the hardware overview of the Biostar K8VGA-M motherboard, including supported CPUs, memory types, and the layout of connectors and expansion slots. Detailed sections describe the BIOS features, power management options, and built‑in peripherals such as LAN, audio, and USB interfaces.
Installation instructions, BIOS configuration steps, and a troubleshooting guide are included to help users set up the board correctly and resolve common issues such as CMOS failures or invalid configurations. This manual is written in Japanese.
| CPU socket | Socket 754 |
|---|---|
| Supported CPUs | AMD Athlon 64 / Sempron |
| Memory type | DDR 266/333/400 MHz |
| Expansion slots | 3 PCI, 1 AGP 8x, 1 CNR |
| LAN controller | VT6103L 10/100 Mbps |
| SATA ports | 2 Serial ATA |
| USB ports | 4 USB 2.0 |
| BIOS | Award BIOS, supports APM1.2, ACPI, USB |
It uses a Socket 754 for CPU installation.
Four USB 2.0 ports are available.
The VT6103L controller provides 10/100 Mbps Ethernet.
