PT88P-A7 Motherboard User Manual

This is a user manual for the PT88P-A7 motherboard

PT88P-A7 Motherboard User Manual - cover page
Brand
PT88P-A7
Category
Motherboard
Document type
User Manual
Language
English
Pages
61
File format
PDF
File size
10.2 MB
Published
05 April, 2012
Updated
30 September, 2023
MD5 checksum
D913B04089C3E307E1BA43AFF5EA1AC4
PDF
PT88P-A7 Motherboard User Manual PDF

About this manual

This manual covers the PT88P-A7 motherboard, detailing its hardware specifications, supported CPUs, memory modules, and expansion slots. It includes FCC compliance information, BIOS settings, and troubleshooting notes.

The document also lists connector types such as SATA, USB, Ethernet, and audio ports, and provides guidance for installing the board in an ATX chassis and configuring system components.

What's inside

  • FCC Information and Copyright
  • CPU Socket and Supported Processors
  • Memory (DIMM) Slots
  • Expansion Slots (AGP, PCI‑Express, PCI)
  • Storage Interfaces (IDE, SATA)
  • Peripheral Connectors (USB, Ethernet, Audio)
  • ATX Form Factor Dimensions
  • BIOS Configuration

Specifications

CPU socketSocket 775
Supported CPU speedup to 3.8 GHz
ATX form factor29.35 cm × 23.05 cm
AGP slotAGP 3.0 (8X)
PCI‑Express slotPCI‑Express x1
Ethernet10/100 Mbps
USB ports4 × USB 2.0
