GA-8I848P(-G)P4 Titans series motherboard chinese installation Manual

Specifications of GA-8I848P-G/GA-8I848P motherboard, supports Intel® 845(GE/PE) / 845(E/G) / 850(E) / E7205 / 865(G/PE/PL/P) / 875P / 848P

GA-8I848P(-G)P4 Titans series motherboard chinese installation Manual - cover page
Brand
GA-8I848P(-G)P4
Category
Motherboard
Document type
Installation Guide
Language
Chinese
Pages
103
File format
PDF
File size
11.4 MB
Published
05 April, 2012
Updated
30 September, 2023
MD5 checksum
922CFDFABE1F1F9C25A0DB8DE13124F9
PDF
GA-8I848P(-G)P4 Titans series motherboard chinese installation Manual PDF

About this manual

This manual provides step‑by‑step instructions for installing the Gigabyte GA-8I848P(-G) motherboard, covering CPU, memory, I/O, and BIOS configuration. It also includes compliance declarations and safety information required for proper setup.

The document lists the hardware specifications, supported processors, expansion slots, and peripheral connections, and offers troubleshooting tips and service contact details for Gigabyte support centers worldwide. This manual is written in Chinese.

What's inside

  • Declaration of Conformity
  • CPU and Memory Installation
  • BIOS Setup
  • I/O Ports Overview
  • Expansion Slots and AGP Configuration
  • SATA and USB Connections
  • Safety and Compliance
  • Support and Service Information

Specifications

CPU SocketSocket478
ChipsetIntel 848P
PCI Slots5 PCI 33 MHz slots
AGP InterfaceAGP 4X/8X (1.5 V)
SATA Ports2 Serial ATA ports
USB Ports8 USB 2.0/1.1 ports
LAN ControllerMarvell 8001 (10/100/1000 Mbit)

Frequently asked questions

What CPU socket does the GA-8I848P(-G) motherboard use?

It uses a Socket478 CPU socket for Intel Pentium 4 processors.

How many USB ports are provided on the GA-8I848P(-G) board?

The motherboard provides eight USB 2.0/1.1 ports.

Which AGP speeds are supported by this motherboard?

It supports AGP 4X and 8X operation at 1.5 V.

What type of LAN controller is integrated on the board?

A Marvell 8001 controller providing 10/100/1000 Mbit Ethernet.
