Embedded Network Hard Disk Recorder User Manual, introduces the product overview, installation instructions, operation essentials, basic operation guide, parameter setting operation guide, management tools and other content.
The Tonghe Ming DS-8016HS is a digital video recorder that supports both video (DVR) and audio (DVS) functions. It can operate independently or as part of a larger security system, handling high‑capacity storage and network connectivity.
This manual provides safety notices, installation steps, interface descriptions, configuration procedures, and a troubleshooting guide to help users set up and maintain the recorder safely and efficiently. This manual is written in Chinese.
| Video Input Channels | 16 PAL/NTSC |
|---|---|
| Audio Input Channels | 16 |
| Audio Compression | OggVorbis 16 Kbps |
| Supported Video Formats | PAL, NTSC, variable frame rates |
| Storage Interface | IDE (SATA), FAT32 |
| External Storage | USB, SD Card, USB‑C, DVD‑RW |
| Power Supply | 110 V / 220 V AC |
If the POWER LED stays off, the power supply may be faulty, the power cable not properly connected, or the internal ATX power circuit may have failed.
Check for short circuits on the motherboard, verify that all cables are correctly seated, and ensure that the firmware version matches the hardware.
Alarm inputs use BNC connectors, while alarm outputs also use BNC connectors as described in the interface table.
