The EWH‑D3 is a wall‑mounted electric water heater equipped with safety features such as a double‑pole high‑temperature limit switch, a pressure‑relief valve, and a three‑pole power‑cutoff device. The manual explains user responsibilities, safety precautions, and the importance of professional installation.
Installation steps include preparing a suitable wall, mounting brackets, connecting the inlet and outlet pipes, installing the pressure‑relief valve (model G1/2‑0.8, preset to 0.8 MPa), wiring the electrical supply, and optional line‑control connections. The guide also details heating mode selection, LED display functions, and maintenance record keeping. This manual is written in Chinese.
| Safety pressure valve model | G1/2-0.8 |
|---|---|
| Safety pressure setting | 0.8 MPa |
| Low‑power heating | 1250 W (whole tank) |
| Fast‑half heating | 2500 W (upper half) |
| Fast‑full heating | 2500 W (whole tank) |
Three options are available: low‑power (1250 W) heats the whole tank, fast‑half (2500 W) heats the upper half, and fast‑full (2500 W) heats the entire tank.
