The Sacon ZTD110 series disinfection cabinet uses UV lamps (200‑275 nm) and ozone to sterilize kitchenware, with an added PTC heating element for thorough drying. It can handle stainless‑steel trays up to 85 °C, has a 116 L capacity, and features a sealed door that locks during operation to prevent ozone leakage. The control panel offers touch switches, a digital clock, and multiple program modes for disinfection, drying and timed operation.
Installation requires mounting the cabinet on a stable surface, keeping a minimum 15 cm clearance from gas appliances or open flames, and connecting the power cord to a 220 V/50 Hz outlet. The manual details wiring, door‑lock wiring, and safety precautions such as avoiding moisture exposure. Operation instructions explain how to set the clock, select disinfection cycles, adjust drying times, and power off the unit safely. This manual is written in Chinese.
| Model | ZTD110K-05F / ZTD110-04D2 / ZTD110-05A / ZTD110-05B2 |
|---|---|
| Control form | Touch switch |
| Rated voltage / frequency | 220 V / 50 Hz |
| Input power | 300 W |
| Disinfection method | UV + ozone |
| Heating method | PTC heating element |
| Capacity | 116 L |
| UV lamp power | 15 W |
| UV lamp life | > 5000 h |
| Load weight (tray) | 2 kg |
| Ozone concentration | 42 mg/m³ |
| UV intensity | > 200 µW/cm² |
| Dimensions (W×H×D) | 650 mm × 595 mm × 450 mm |
| Net weight | 30 kg |
Press the “Function” key to select the “Clock” menu, then use the “Adjust” keys: press the first adjust key to change the hour, and the second adjust key to change the minutes.
The standard disinfection program runs for 35 minutes, followed by a drying phase that continues until the timer reaches 00:00.
Maintain a safety clearance of at least 15 cm between the cabinet and any gas appliance or open flame.
Yes, the cabinet can be mounted on the lower or upper part of a countertop, ensuring it is level and not tilted.
