This manual covers the two manuals (upper and lower) and pedal board of Kawai electronic organs, describing the Keyboard Conductor panel that lets the player select voice groups and adjust individual volumes. It explains voice groups for Tibia, Orchestra, and preset instruments, as well as the Synthesizer, Effects, Rhythm Section, and automatic accompaniment functions.
Additional sections detail program registration, program sequencer, MIDI connections, front and rear panel connectors, and technical specifications such as key counts and pedal notes. The document is multilingual but the core operating instructions are presented in English.
| Upper and lower manuals key count | 49 keys per manual (61 keys on KX5000) |
|---|---|
| Pedal board note count | 13 notes (25 notes on KX5000) |
Each manual has 49 keys; the KX5000 model has 61 keys per manual.
The organ provides MIDI jacks on the front panel and MIDI connectors on the rear panel.
