The TDA2054M is a monolithic linear integrated circuit designed for low‑noise, low‑distortion preamplification in cassette recorders, dictaphones, telephonic equipment, and Hi‑Fi applications. It features an automatic level control (ALC) system with stereo matching better than 3 dB and a high‑gain equalization amplifier.
The document lists absolute maximum ratings, electrical characteristics, mechanical dimensions, connection diagrams, and typical performance data, helping designers integrate the device into audio circuits and evaluate its behavior under various operating conditions.
| Total power dissipation (25 °C) | 600 mW |
|---|---|
| Storage and junction temperature range | -40 °C – 150 °C |
The maximum power dissipation is 600 mW at 25 °C.
It can be stored and operated from –40 °C up to 150 °C.
