The GD20E dehumidifier uses a refrigeration principle to remove moisture from indoor air, offering a 20 L/day dehumidifying capacity and a quiet mode for low‑noise operation. It features a 6 L drainage tank, an air filter, and multiple operation modes (Low, Medium, High, Quiet, Continuous).\n\nThe manual explains how to install the unit, operate the control panel, drain and clean the tank, maintain the air filter, and store the device safely. Safety notations, troubleshooting steps, and specifications such as power consumption and operating temperature range are also included.
| Power Supply | 220~230V, 50Hz |
|---|---|
| Dehumidifying Capacity | 20 L/day |
| Power Consumption | 400 W |
| Drainage Tank Capacity | 6.0 L (automatic stop at about 5.5 L) |
| Weight | 14 kg |
| Dimensions (W×D×H) | 545 mm × 380 mm × 261.5 mm |
| Operating Temperature Range | 2 °C to 38 °C |
Plug the power supply into an outlet, open the louver, press the power switch, and select an operation mode or let it run in the default mode.
The tank full indicator lamp lights when the drainage tank reaches about 5.5 L, stopping operation automatically until the tank is emptied and correctly positioned.
Yes, connect a 15 mm‑inner‑diameter hose to the continuous drainage port, ensuring the hose is lower than the port and not blocked.
