This manual begins with important safety instructions for using the central dust‑collection system, emphasizing that it is intended for indoor dry dust only and must be powered from a 220 V/50‑60 Hz source. It details how to install the dust‑bag, connect the retractable hose, and prepare the unit before each use.
Subsequent sections cover normal operation, including hose extension, selecting appropriate suction nozzles, and automatic dust‑bag detection. The troubleshooting chapter lists common faults such as power‑indicator warnings, reduced suction, and hose blockages, and provides step‑by‑step corrective actions. This manual is written in Japanese.
| Air power (Air watt) | 380 |
|---|---|
| Applicable area | 80 m² |
| Maximum hose length | 45 m |
| Suction power | 105 (unit unspecified) |
| Air flow | 212 m³/h |
| Motor model | Ametek 1300M |
| Current | 5.7 A |
| Voltage | 220‑230 V, 50/60 Hz |
| Noise level | 65 dBA |
| Weight | 9.5 kg |
| Dimensions (W×H×D) | 440 mm × ? mm × 860 mm |
No, the system is designed for dry dust only and must not be used to vacuum water or other liquids.
