This guide explains how to safely unpack, install the driver software, and connect the Uniscan TS scanner to a computer via USB. It includes detailed safety precautions, recommended USB cable usage, and instructions for installing optional applications such as Uniscan Manager and Presto! Image Folio.
After installation, the manual covers testing the scanner, using the five function keys (File, Copy, Scan, OCR, E‑mail), and configuring button settings through the Uniscan Manager. It also provides an overview of the included OCR software and tips for exporting scanned data to Excel or HTML. This manual is written in Chinese.
| Dimensions | 226 mm × 256 mm × 32 mm |
|---|---|
| Weight | 0.95 kg |
| Operating Temperature | 10 °C – 40 °C |
| Maximum Scan Area (Reflective) | 241 mm × 145 mm |
| Color Input Bit Depth | 48‑bit |
| Color Output Bit Depth | 24/48‑bit |
| Grayscale Input Bit Depth | 16‑bit |
| Grayscale Output Bit Depth | 8/16‑bit |
| Black‑White Bit Depth | 1‑bit |
| Optical Resolution | 600 dpi |
| Maximum Hardware Resolution | 600 dpi × 1200 dpi |
| Maximum Software Resolution | 19200 dpi |
| Interface | USB 1.1 |
| Light Type | RGB LEDs |
| Power Consumption (Operating) | 2.5 W |
| Power Consumption (Standby) | 1.0 W |
Insert the square USB connector into the scanner’s rear USB port, then plug the rectangular USB connector into a USB port on the computer or a USB hub.
You need to install the driver CD’s applications, such as Uniscan Manager, Presto! Image Folio, THOCRXP, or ABBYY FineReader, otherwise some keys will not work.
The scanner can capture up to 241 mm × 145 mm for reflective (white) documents.
