This is a user manual for Uniscan scanner produced by Tsinghua Unisplendour Incorporated, which introduces the installation and use of the scanner, including scanner safety precautions, unpacking the scanner, installing and setting up the scanner, using the function buttons on the scanner, and maintenance.
This manual provides step‑by‑step instructions for installing the Tsinghua Uniscan scanner, including unpacking, connecting the supplied USB cable, installing drivers and software, and performing an initial test scan. Safety precautions and handling guidelines are also covered to prevent damage and ensure reliable operation.
The guide details the functions of the scanner’s five hardware buttons (File, Copy, Scan, OCR, Email), how to configure button settings via the Uniscan Manager software, and troubleshooting tips for common issues such as driver errors, OCR failures, and scan quality problems. A full specifications appendix lists physical dimensions, power consumption, resolution limits, and supported interfaces. This manual is written in Chinese.
| Physical dimensions | 226 × 256 × 32 mm |
|---|---|
| Weight | 0.95 kg |
| Operating temperature | 10 °C to 40 °C |
| Maximum scan area (reflection) | 241 mm × 145 mm |
| Optical resolution | 600 dpi |
| Maximum hardware resolution | 600 dpi × 1200 dpi |
| Maximum software resolution | 19200 dpi |
| Power consumption (operating) | 2.5 W |
| Power consumption (standby) | 1.0 W |
| Interface | USB |
The manual states you must use the supplied USB cable; using other USB cables may cause the scanner to malfunction.
The scanner’s optical resolution is 600 dpi.
