This manual introduces installation, wiring, debugging, running, maintenance and fault troubleshooting of CDI9000 series inverters, as well as function description.
This manual covers safety precautions for the CDI9000 series frequency transformer, including warnings about electrical shock, fire hazards and proper handling of high‑voltage components. It also explains the acceptance inspection process and how to verify model and part numbers before installation.
Detailed sections describe site selection, mounting clearances, wiring of the main and control circuits, configuration of digital operators, RS‑485 communication, and routine maintenance. Appendices provide technical specifications, dimension drawings, rated output current tables, and optional accessories such as regenerative braking units and radio‑noise filters. This manual is written in Chinese.
| Input Voltage | AC 3‑phase 380 V ±15 % |
|---|---|
| Output Voltage | AC 3‑phase 0‑380 V |
| Output Frequency Range | 0‑300 Hz |
| Power Rating Options | 1.5 kW, 11 kW, 160 kW |
Press the lock tab on the digital operator downward to release it from the front cover, then push it back into the panel; the lock tab will automatically secure it.
The CDI9000‑G1R5T4 model requires an input of AC 3‑phase 380 V ±15 % at 50/60 Hz.
