This manual introduces the basic operation, function parameters, alarm code types and other information of the EDS760 series inverter to help you better use the inverter.
This manual covers safety information and precautions for the EDS760 frequency transformer, including proper grounding, avoiding water exposure, and preventing operation in explosive environments. It also details the model specifications, terminal assignments, and functional parameters of the device.
Installation guidelines describe the correct wiring of input and output terminals, mounting requirements, and dimension data. Operational sections explain basic control functions, speed settings, and fault troubleshooting procedures. This manual is written in Chinese.
| Dimensions (W × H × D) | 138 × 100.6 × 149 mm |
|---|
The transformer must be properly grounded, kept away from water, and not installed on flammable or explosive materials.
Key terminals include PF1 for control signals and U, V, W as the three-phase output terminals.
