The WRT‑RI smart networking intercom system consists of a building main unit, user extensions, a management‑center computer and auxiliary equipment. It supports up to 238 main units and 5 wall units, offers multi‑channel communication, and includes features such as remote unlocking, eight alarm zones and visual monitoring.
This guide details the installation precautions, wall‑mount mounting method, wiring connections, and basic usage functions like calling the management center, viewing messages, and handling simple faults. This manual is written in Chinese.
| Maximum main units | 238 |
|---|---|
| Maximum wall units | 5 |
| Recommended mounting height | 145 cm |
| Disarm password length | up to 8 digits |
| Alarm zones | 8 zones |
The intercom should be installed at about 145 cm height.
The system can connect up to 238 main units and 5 wall units.
The disarm password can be up to 8 digits long.
Press the call key (标记为 “襄”) on the intercom to call the management center.
