This document is an operation manual for the CHILLER, including product quality assurance, precautions, and usage conditions.
The manual covers all aspects of the CULS‑200 series chillers, including safety precautions, installation requirements, and detailed operation of the temperature controller. It also contains troubleshooting advice and regular maintenance tasks to keep the equipment running reliably.
Key sections include safety symbols and warnings, system installation, control‑panel functions, fault diagnosis, and a full set of technical specifications such as dimensions, cooling capacity, and power consumption. This manual is written in Chinese.
| Model Dimensions (L×W×H, mm) | 1300 × 700 × 1330 |
|---|---|
| Cooling Capacity (kW) | 14.6 |
| Input Power (kW) | 4.0 |
| Water Pump Power (kW, 50 Hz) | 0.75 |
| Maximum Flow Rate (L/min) | 400 |
| Operating Temperature Range (°C) | 5‑40 |
Do not modify the equipment, wear safety shoes and gloves, keep the area dry, and follow all warning labels to avoid high‑voltage or high‑pressure hazards.
The inlet water pressure should be between 1.0 and 4.0 kg/cm².
The CULS‑205W measures 1300 mm long, 700 mm wide, and 1330 mm high.
The chiller is designed for ambient temperatures from 5 °C to 40 °C.
