This is a brand new digital music player that supports MP1, MP2, MP3, WMA, WMV, ASF, WAV, AMV, etc. Its perfect sound quality, high reliability and exquisite appearance are perfectly matched, and it is a master-level work. I sincerely hope that it will bring you an extraordinary experience in the digital age.
This manual describes the functions and operation of a digital portable MP3 player, including audio playback, movie mode, voice recording, FM radio, and system settings. It provides step‑by‑step instructions for using the device, charging the built‑in lithium‑ion battery, and upgrading firmware.
The document also contains troubleshooting tips for common issues such as power problems, headphone sound, FM reception, and file transfer, plus a full list of technical specifications for the hardware and supported formats. This manual is written in Chinese.
| Dimensions | 61.5 mm (L) × 42 mm (W) × 14 mm (T) |
|---|---|
| Weight | 339 g |
| Display | 1.5‑inch CSTN 128 × 128 pixels |
| USB Interface | USB 2.0 Full Speed (read 1000 KB/s, write 900‑1000 KB/s) |
| Maximum Playback Time | 8 hours |
| Sampling Rate | 8 kHz |
| Recording Formats | WAV (32 kbps) and ACT (8 kbps) |
| Recording Time | 35 hours (ACT, 128 MB Flash) |
| Headphone Output | 10 mW per channel (32 Ω) |
| MP3 Bitrate Range | 8 kbps – 320 kbps |
| Frequency Response | 20 Hz – 20 kHz |
| Signal‑to‑Noise Ratio | 85 dB |
| Operating Temperature | -5 °C to 40 °C |
| Supported Operating Systems | Windows 98/ME/2000/XP, Mac OS 10, Linux 2.4.2 |
Make sure the device is switched on; the manual advises checking that the power switch is in the ON position.
Check that the volume is not set to zero and that the headphones are properly connected.
Adjust the position of the player and the headphones, and turn off nearby electrical devices.
Check that the USB cable is not damaged and that the connection to the computer is secure.
