This document is an instruction manual for the PC 1600x™ product. The main content includes warning messages and usage instructions. The warning messages are mainly to alert users to the presence of uninsulated dangerous voltage inside the product that may pose a risk of electric shock, and to emphasize that the cover should not be opened and the appliance should not be exposed to rain or moisture. The usage instructions include the operation guide and maintenance tips for the product.
This manual warns users about the presence of uninsulated dangerous voltage inside the PC 1600x enclosure and advises that the cover must not be opened. Maintenance should be performed only by qualified service personnel, and the unit must be kept dry to avoid shock or fire hazards.
The guide then describes the PC 1600x MIDI Control Station’s features, including 16 programmable faders, 16 programmable buttons, a data wheel, CV pedal inputs, and a 20‑character LCD. It covers preset and scene management, MIDI filtering, power requirements, front and back panel connections, and provides extensive appendices for SysEx messages and MIDI implementation details.
| Power Supply | 16‑16.5 VAC, 1000 mA adapter (Peavey part #70900660) |
|---|---|
| Number of Faders | 16 programmable faders |
| Number of Buttons | 16 programmable buttons |
| Presets | 50 presets (0‑49) |
| Scenes | 100 scenes |
No – opening the cover can expose dangerous uninsulated voltage and may cause electric shock.
Use only the supplied 16‑16.5 VAC, 1000 mA adapter (Peavey part #70900660).
The unit supports 50 presets, numbered 0 through 49.
There are 16 programmable faders.
