The AD73360 is a six-input channel analog front end with 6 16-bit A/D converters, programmable input sample rate, simultaneous sampling, 77 dB SNR, 64 kS/s maximum sample rate, -83 dB crosstalk, low group delay (25μs typical per ADC channel), programmable input gain, flexible serial port, which allows multiple devices to be connected in cascade, single (+2.7 V to +5.5 V) supply operation, 80 mW max power consumption at +2.7 V, on-chip reference, 28-lead SOIC and 44-lead TQFP packages
The AD73360 is a six‑channel, 16‑bit analog‑to‑digital converter designed for general‑purpose analog input, industrial power metering, motor control, and simultaneous‑sampling applications. It provides up to 77 dB SNR, programmable input gain (0‑38 dB), and a flexible serial port that supports cascade operation.
The device operates from a single 2.7 V to 5.5 V supply, consumes up to 80 mW, and is available in 28‑lead SOIC and 44‑lead TQFP packages. Detailed specifications, timing characteristics, pin configurations, and ordering information are provided in the following sections.
| Number of ADC channels | 6 |
|---|---|
| Resolution | 16‑bit |
| Signal‑to‑Noise Ratio (SNR) | 77 dB |
| Maximum sample rate | 64 kS/s |
| Power consumption | 80 mW max at 2.7 V |
| Operating temperature range | -40 °C to +85 °C |
| Package options | 28‑lead SOIC, 44‑lead TQFP |
The AD73360 can sample at up to 64 kS/s.
It is offered in a 28‑lead SOIC package and a 44‑lead TQFP package.
The device operates from –40 °C to +85 °C.
Maximum input range is 1.644 V p‑p when AVDD = 3 V.
