Foxconn K8T890M2AA Motherboard User Manual

K8T890M2AA series motherboard manual, introduces the features and characteristics of the motherboard and how to use it.

Brand: K8T890M2AA系列主板中文使用手册
Category: Motherboard
Document type: User Manual
Language: Chinese
Pages: 46
File format: PDF
File size: 5.9 MB
Published: 22 March, 2012
Updated: 30 September, 2023
MD5 checksum: 34436A58A89B2C90D43E7EE2A5C0D166
PDF: Foxconn K8T890M2AA Motherboard User Manual PDF

About this manual

This manual covers the K8T890M2AA series motherboard, detailing its features, layout, and supported components. It includes sections on product introduction, main specifications, motherboard layout, and installation procedures for CPU, memory, and power.

Additional chapters guide users through BIOS configuration, system monitoring, and driver/software installation from the supplied CD. Safety notices, compliance statements, and troubleshooting tips are also provided. This manual is written in Chinese.

What's inside

Product Introduction
Main Specifications
Motherboard Layout
Installation Guide
BIOS Settings
System Monitoring
Driver Installation
Expansion Slots
Onboard Audio
Power Management

Specifications

Form factor	ATX, 305mm x 201mm
CPU socket	Socket AM2, AMD Athlon 64x2, etc.
Chipset	VIA K8T890 northbridge, VT8237R Plus southbridge
Memory slots	2 DDR2 240‑pin slots
Maximum memory	2 GB
USB ports	8 USB 2.0 ports
SATA	2 SATA ports, 150 MBps, RAID 0/1/JBOD

Frequently asked questions

How do I save BIOS settings and exit the setup?

Select the ‘Save & Exit Setup’ option, press when prompted to save to CMOS and exit, or press / to cancel.

How can I install the motherboard drivers from the CD?

Insert the driver CD; it will auto‑run. Install the VIA Chipset Driver first, then use the one‑click installer to add the remaining drivers and software.

What CPUs are supported by this motherboard?

The board supports AMD socket AM2 processors, including Athlon 64 X2 dual‑core, Athlon 64 FX, Athlon 64, and Sempron models.
