K8M890M2MB series motherboard user manual, including product features, usage methods, precautions and other information.
This manual provides detailed information for the K8M890M2MB series motherboard, including hardware layout, supported components, BIOS configuration, and driver installation procedures. It also contains safety notices, symbol explanations, and compliance statements.
The document is organized into chapters covering main performance specifications, board layout, CPU and memory installation, peripheral connectors, BIOS menus, power management, system monitoring, and step‑by‑step driver installation with accompanying software tools. This manual is written in Chinese.
| CPU socket | Socket AM2 |
|---|---|
| Chipset | VIA K8M890 (northbridge) + VT8237A (southbridge) |
| Supported memory speeds | DDR2 800/667/533 |
| SATA ports | 2 |
| USB ports | 8 × USB 2.0 |
| LAN options | 10/100 Mbps (‑L) or 10/100/1000 Mbps (‑K) |
It uses a Socket AM2 compatible with AMD Athlon 64 X2, Athlon 64 FX, Athlon 64 and Sempron processors.
The board is built around the VIA K8M890 northbridge and the VIA VT8237A southbridge.
The motherboard provides two SATA connectors.
Select “Quit Without Saving”, press Y to confirm, and the BIOS will exit without saving.
