The manual begins with safety precautions, including proper power handling, ventilation, and cleaning of the laser lens. It explains how to insert and remove discs, operate the remote control, and use the front‑panel buttons for playback, programming, and navigation.
It also covers equipment connections (AV, component, CVBS, S‑Video, YPbPr), troubleshooting tips, and a full list of technical specifications such as supported disc formats, video resolution, audio performance, power requirements and dimensions. This manual is written in Chinese.
| Model | KVD-799SK |
|---|---|
| Video Standard | NTSC/PAL60/PAL/Auto |
| Supported Disc Formats | DVD, VCD, CD, SVCD, CD‑R, CD‑RW, DVD‑R, DVD‑RW |
| Video Resolution | 1250 lines |
| Video SNR | 56 dB |
| Audio Frequency Response | 4 Hz‑44 kHz ±1 dB |
| Audio SNR | 90 dB |
| Dynamic Range | 90 dB |
| D/A Conversion | 96 kHz / 24‑bit |
| Power Supply | 110 V / 60 Hz |
| Power Consumption | 25 W |
| Dimensions (W×H×D) | 430 mm × 38 mm × 240 mm |
| Weight | 3.0 kg |
Use a dry cloth and wipe the disc from the center outward; do not use gasoline, alcohol, or abrasive cleaners.
It operates on 110 V AC at 60 Hz.
