This document is a motherboard user manual that provides installation information. The document explains copyright protection, applicability, and risk responsibility. In addition, the document mentions information related to operating systems and other trademarks.
This manual provides step‑by‑step instructions for installing the 935-975X01-144G motherboard, configuring hardware components, and setting up BIOS options such as RAID and CrossFire. It also includes safety precautions, anti‑static measures, and a detailed parts list.
Additional sections cover software driver installation, power‑management features, USB and network wake‑up functions, and a thorough troubleshooting guide with error‑code explanations and diagnostic checklists. This manual is written in Chinese.
| CPU socket | LGA 775 |
|---|---|
| Supported CPUs | Intel Pentium D, Pentium 4, Core2 (Conroe) |
| Chipset | Intel 975X Express (Northbridge) / ICH7R (Southbridge) |
| Memory slots | 4 × 240‑pin DDR2 DIMM, up to 8 GB |
| Supported memory speeds | DDR2‑533 / DDR2‑667 |
| PCI Express slots | 2 × PCI‑Express x16, 1 × PCI‑Express x4, 1 × PCI‑Express x1 |
| Network interface | Realtek RTL8111B Gigabit LAN |
| Audio codec | Realtek ALC882, 8‑channel output |
It uses an LGA 775 CPU socket.
The board provides four 240‑pin DDR2 DIMM slots.
