This document is the user manual for the V5 digital soft starter. It provides information on delivery, unpacking, safety precautions, and more.
This manual provides the necessary information to install, configure, and operate the Power Electronics V5IM01AC digital soft starter. It includes safety guidelines, wiring diagrams, parameter settings, and fault handling procedures.
The document is organized into sections on mechanical installation, electrical connections, LCD display functions, control terminals, parameter adjustment, and detailed fault codes, helping technicians and end‑users ensure reliable performance of the soft starter. This manual is written in Japanese.
| UNLOAD T2 range | 0‑99/Off |
|---|---|
| SHRPIN2 range | 0.7‑1.2/Off |
| 1MTR2 current range | 9‑1200 A |
| V MTR2 voltage range | 1‑27374 V |
| P MTR2 power range | 0‑999 kW (max 4.0 kW) |
| COS PHI 2 range | 40‑999 % (typical 85 %) |
| Frequency (FREQ 2) | 50 Hz |
Use the AUTO RESET function; set the AUTO RESET parameter to the desired value and confirm the reset.
The LCD shows operational status, parameter values, fault codes, and allows navigation through menus for configuration.
The control terminals are listed under the section “控制端子” and include inputs for start/stop, speed reference, and external communication.
