This manual provides detailed instructions for installing, operating, and maintaining the TCL HD29E64S and HD29M63S digital high‑definition televisions. It includes safety warnings, remote‑control functions, menu navigation, and basic troubleshooting steps.
The guide also lists technical specifications such as supported video formats, input connectors, power consumption, and physical dimensions, helping users configure the TV for optimal performance. This manual is written in Chinese.
| Receiving Channels | 470 MHz full‑channel cable TV (DS1‑57CH Z1~Z38CH) |
|---|---|
| Supported TV Standards | PAL, NTSC |
| RF Antenna Input | 75 Ω unbalanced |
| AV1/AV2/AV3 Input | Video 1.0 Vp‑p; Audio 0.5 VRMS |
| S‑Video Input | Luminance 1.0 Vp‑p; Chrominance 0.7 Vp‑p |
| Power Consumption | 120 W |
| Rated Voltage | 220 V ~ 50 Hz |
| Screen Size | 68 cm |
| Dimensions (W×D×H) | 785 × 452 × 600 mm (HD29E64S) / 785 × 425 × 631 mm (HD29M63S) |
| Weight | 43 kg |
Press the power button on the TV unit to turn it on; to turn it off, press the standby button on the remote or the power button on the TV.
Use the program +/‑ keys on the TV or remote to step through channels, or press the numeric keys followed by OK to enter a channel number (0‑255).
Open the Image menu via the MENU key, then use the program +/‑ keys to select a setting and the volume +/‑ keys to adjust its value.
Open the battery compartment on the remote, insert two AA 1.5 V batteries with the correct polarity, and close the cover.
